Phezer P17 Handheld Inkjet Printer Date Number Expiry Date Logo QR Bar Batch Code Expiry Date 12.7mm Label Printer 28 Languages

Big advantage:

1: The machine is not encrypted, and the cost of ink cartridges is low. You can also buy cartridges

locally.

2: The printing height of this product is 12.7 mm, the printing efficiency is better, the speed is

faster, it is suitable for printing almost all materials such as carton, plastic bag, metal, etc., quick-

drying printing, not easy to fade

3: This machine supports 28 languages, and you can use U disk to import new fonts.

include:

1* Printer

1* Charger

1* Stylus Pen

1* Positioning metal plate

1* battery

1 * Ink (Select the option that includes ink cartridge)

1* English manual

Specification:

1,Print Head:Thermal inkjet 2.5

2,CPU:Quad core 1.4GHz

3,Operation System:Linux

4,Print Distance:Best quality with 2-5mm

5,lnterface:USB,Photocell

6,Print Resolution:600dpi Maximum

7,Weight:Gw 0.42KG

8,Dimension:225*135*110mm

9,Battery:2200mAh @ 8.4V

10,Ink Type:Water-based/42ml,Solvent/42ml

11,Material of Printer:ABS+PC

12,Print Height:2-12.7mm

13,Language:Chinese, English, Japanese,Turkish,Arabic, Korean, Spanish, French, Italian and so

14,Adapter:AC input 100~240V; DC output 8.4V/2A

15,Ink Color:Black, White,Red, Yellow, Blue, Green, Invisible, UV

16,Print Content:Chinese,English, Numbers,Symbols, QR code, Bar code,Pictures, Dates,Counter

17,Print Media:Boards, Carton, Stone, Pipe,Cable, Metal, Plastic,Electronic,Automotive parts

18,Operational Environment:Temperature 0-45 (The best:20-30)Humidity 40%-60%Rh

Q & A

1QHow to better extend the life of the printer

A:Before installing and removing ink cartridges, be sure to turn off the printer.

2.Q:How to better protect the ink cartridge nozzle?

A:When not using ink cartridges, please close the protective cover in time.

Dip a soft paper towel with a small amount of alcohol before use, and then gently wipe the nozzle in one direction.

3.Q: Why does the printer screen not work?

A: When you find that the screen of the printer is not working, please calibrate the screen of the printer.For specific steps please check this link :

4.Q: Can the printer be equipped with photoelectric sensors?

A: Yes, our inkjet printer has an adapted photoelectric sensor. Please consult customer service before purchasing.

5.Q: Can the printer print on the bottle?

A: Yes, we will provide you with a metal positioning plate for free, For specific steps,please consult customer service .

6.Q: What should I do if the printer cannot print?

A: Check whether the timing belt on the left side of the printer is off (not in the groove).

Check if there is ink in the ink cartridge.

Switch the nozzle of the printer in the settings.

After turning off the printer, reinstall the ink cartridge.

7.Q: The ink cartridge of the printer can print, but the printing is not clear, what should I do?

A: Check whether the ink cartridge nozzle is clean and dry, and wipe the nozzle carefully with a clean soft tissue.

Take out the ink cartridge when the printer is off, shake the nozzle down several times, and stick a clean paper towel on the surface of the nozzle to divert the ink in the box.

Switch the nozzle of the printer in the settings.

The above operation still cannot be solved, please replace the ink cartridge.

8.Q: What should I do when there is a printer phenomenon of wire drawing?

A: The ink cartridge is quick-drying. When there is a phenomenon of wire drawing, please wipe the nozzle carefully with a clean soft tissue and switch the nozzle of the printer.

When not using the ink cartridge, please install the cover in time.

9.Q: Can the printer be charged?

A: Yes. Note:

Please remove the battery at the bottom of the printer and charge it separately to avoid damage to the printer.

Please use our special charger to charge the printer.

When the printer is stored for a long time and not in use, it is recommended to safely charge and discharge it every three months.

==========

Hign-concerned Chemical : None

Voltage : 220-240V

Max. Resolution : 600dpi

Signal Connection Type : None

Print Speed : 28ppm

Double-sided Printing : No

Supports Network Printing : No

Paper Feed Mode : Manual

Max Paper Size : A4

Type : Inkjet Printer

Interface Type : USB

Origin : Mainland China

Certification : CE

Print Height : 2-12.7mm

Display : 4.3 inch touch screen

Print Area : 1-8 lines or unlimited

Print speed : 80meter/minute

Battery : 10 hours of continuous

ink cartridge : print 800000

barcode printer : expiry date printer

label printer : hand jet printer

handheld inkjet printer : variable

mobile printer : portable printer

plastic bottle printer : paper box printer

wood printer : metal printer

steel printer : cloth printer

online TIJ printer : print automatically

handheld printer : print by hand
